Product SRI
Fire Extinguishers
Available Variations:
- FEX139-CS-020-RD
- FEX139-CS-050-RD
Product description
| variations | FEX139-CS-020-RD | FEX139-CS-050-RD |
| Material | Carbon Steel | |
| Capacity (kg) | 2.0 | 5.0 |
|
Working pressure (Bar)
|
60.0 at 270C | |
|
Overall height, mm
|
530 | 770 |
|
Overall diameter, mm
|
113 | 140 |
|
Cylinder test pressure, Bar
|
250 | |
|
Discharge time, sec
|
18-25 | 20-30 |
|
Standard
|
Manufactured and approved to MS1539 Part 1 | |
|
Full weight, Kg
|
8.5 | 18.5 |
|
Paint finish
|
Red | |
|
Fire Rating
|
21B | 55B |
|
Temperature range
|
-20°C to 60°C | |
|
Discharge range
|
3 meter | |
|
Carton size
|
180 x 195 x 665 | 230 x 230 x 715 |
|
Operating head
|
Brass | |
|
Type of extinguishant
|
Carbon Dioxide | |
|
Class of Fire
|
B,C | |
